Product Summary

The TX2-12V is a capacity relay with high surge voltage & high breakdown voltage.

Parametrics

TX2-12V absolute maximum ratings: (1)Arrangement: 2 Form C; (2)Initial contact resistance, max.(By voltage drop 6 V DC 1 A): 100 mΩ; (3)Contact material: Gold-clad silver alloy; (4)Rating: Nominal switching capacity (resistive load): 2 A 30 V DC; Max. switching power (resistive load): 60 W; Max. switching voltage: 220 V DC; Max. switching current: 2 A; Min. switching capacity: 10μA 10 mV DC.

Features

TX2-12V features: (1)Breakdown voltage between contacts and coil: 2,000 V; (2)Surge withstand between contacts and coil: 2,500 V; (3)High contact capacity: 2 A, 30 V DC; (4)Surface-mount type available.

Diagrams

TX2-12V circuit dragram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TX2-12V
TX2-12V
Panasonic Electric Works
Low Signal Relays - PCB 2A 12VDC DPDT NON-LATCHING PCB
Data Sheet
0-1: $1.94
1-25: $1.88
25-50: $1.75
50-100: $1.46
TX2-12V-1
TX2-12V-1
Panasonic Electric Works
Low Signal Relays - PCB 2 Form C 2A 30VDC 12VDCDC
Data Sheet
0-1: $2.35
1-25: $2.15
25-50: $1.92
50-100: $1.63
TX2-12V-TH
TX2-12V-TH

RELAY GEN PURPOSE DPDT 2A 12V
Data Sheet
0-1: $2.45
1-25: $2.25
25-50: $2.00
50-100: $1.70
100-500: $1.50
500-1000: $1.45
1000-5000: $1.40
5000-10000: $1.33
10000-25000: $1.30
